| 効率: | 99％ | 気孔率: | 0.05 um |
|---|---|---|---|
| 上の直径: | 80mm | 一番下の直径: | 140mm |
| 長さ: | 305mm | 重さ: | 0.84 kg |
| 中材料: | ポリエステル + PTFE | ろ過グレード: | HEPAフィルター |
| フィルタリングエリア: | 0.5m2 | 動作温度: | 80 ℃ |
| 微小粒子サイズ: | 0.3μm | 最下ID: | 72mm |
| エンドキャップ: | ステンレス鋼 | インナーコア: | ステンレス穴あきプレート |
| 構造: | コーンフィルター要素 | ||
| ハイライト: | PTFE polyester dust filter cartridge,high efficiency cartridge filter element,0.5 m2 dust filter cartridge |
||
| Attribute | Value |
|---|---|
| Condition | New |
| Efficiency | 99% |
| Construction | Dust Filter Cartridge |
| Porosity | 0.05 μm |
| Dimensions (L×W×H) | (Top)80mm × (Bottom)140mm × (L)305mm |
| Weight | 0.84 KG |
| Warranty | 6 Months |
| Medium Material | Polyester + PTFE |
| Filtration Grade | HEPA Filter |
| Filtering Area | 0.5 m² |
| Service Life | ≥6 months |
| Operating Temperature | 80°C |
| Minimum Particle Size | 0.3μm |
| OEM | Yes |
| Applicable Industries | Manufacturing Plant, Machinery Repair Shops, Energy & Mining |
| Part Number | 0112311 (Replacement Piab Pleated Filter) |
| Structure | Cone Filter Element |
| Dimensions | (Top OD)80 × (Bottom OD)140 × (Bottom ID)72 × (L)305 mm |
| Filter Material | Polyester + PTFE membrane |
| Efficiency | 99.98% (Particles ≥0.3-0.5μm) |
| End Caps | Stainless Steel |
| Inner Core | Stainless Steel Perforated Plate |
| MOQ | No minimum order quantity. Full container recommended for cost savings: 20GP FCL: 3024 sets 40GP FCL: 6132 sets 40HQ FCL: 7154 sets |
| Loading Port | Shanghai |
| Lead Time | Approximately 20 days for 20GP container |
| Payment Methods | T/T, Western Union, PayPal |
| Shipping Options | Sea freight to nearest port Air freight to nearest airport Express (DHL, UPS, FedEx, TNT, EMS) to door |
| Package | Carton |
| Production Capacity | Approximately 1000 pcs per week |
